UPTIME Motion Compensated Telescopic Gangway System
Two (2) 2nd hand systems prompt available
Design & Certification
| Design standard | EN 13852-1 |
| Design temperature range | −20 °C to +45 °C |
| Certification | DNV |
| Key technology | Motion Compensated |
Weights (Approximate)
| Gangway Standalone | 7200 kg |
| Pedestal, tower, HPU, Controls | 17 800 kg |
Gangway Operating Parameters
| Operating wind speed | Up to 20 m/s |
| Operating wave height | Significant wave height (Hs) up to ~2.5 m |
| Operating temperature | −20 °C to +45 °C |
| Telescopic range | 19 m with ±4 m stroke |
Power & Hydraulics
| Main power supply | 3x690 VAC, 3-phase, 60 Hz + 220-240 VAC |
| HPU Power consumption | 2x128kW + 1x11kW (440/690V) |
| Control system | Electro-hydraulic with accumulator backup |
Control & Operation
| Operator station | Control cabin mounted on top of pedestal/tower |
| Interface | Touchscreen HMI for mode selection, status, alarms and diagnostics |
| Manual mode | Proportional handles/joysticks control all axes; release = immediate stop + hydraulic lock |
| Landing sequence | Operator extends/lowers gangway → hydraulic door opens/closes → system switches to Free-for mode |
| Compensation control | Integrated into mode transitions and continuously active during approach and landed operations |
Dimensions
| Retracted length | 15 538 mm |
| Extended length | 23 400 mm |
